Additional information
| Power | single-phase a.c. |
|---|---|
| Rated Voltage | 220-240 V |
| Rated frequency | 50 Hz |
| Maximum Input Current (A) | 14.0 |
| Maximum Input Power (W) | 2800 |
| Cooling Capacity (Btu/h) | 24000 |
| Heating Capacity (Btu/h) | 24500 |
| Power input Cooling (w) | 2190 |
| Power input Heating (w) | 1980 |
| Current input Cooling (A) | 10.2 |
| Current input Heating (A) | 9.3 |
| Noise(indoor/outdoor) dB(A) | 49.57 |
| Air Circulation quantity(indoor) (m3/h) | 1200 |
| Compressor Locked Current (A) | 48 |
| Design Pressure Lo (MPa) | 1.15 |
| Design Pressure Hi (MPa) | 4.15 |
| The maximum operating pressure indoor (MPa) | 4.2 |
| The maximum operating pressure outdoor (MPa) | 4.2 |
| Refrigerant filling quantity(R410a) (Kg) | 1.77 |
| Waterprooft Level(Outdoor) | IP 24 |
| Protection type for shockproof | Class I |
| Climate application type | T1 |
